Navigation
190-02327-03 Rev. C Pilot’s Guide 3-55
Common Page Features
MAP PREVIEW WINDOW
A 2D map of the surrounding area (includes SafeTaxi airport depictions).
Data Fields Waypoint Identifier
• Distance and bearing from
current aircraft position
• Latitude and longitude
• Applicable city, state,
country and/or region
(e.g., “NW USA”)
• Identifier and type icon
This key provides access to
multiple waypoint search options.
These include the FastFind
feature and multiple search tabs.
As you approach an airport, use the map preview function to orient yourself for
such things as pattern entry or runway alignment.
GTN 650Xi SERIES
Tapping Preview displays the
waypoint location on a dedicated
map page.
