Hazard Awareness
190-02327-03 Rev. C Pilot’s Guide 5-5
WX Info Banner
Tapping any weather icon displays an information banner. When applicable, a
pop-up window displays additional data.
WX Display Orientation
Each weather app allows you to set the orientation of the weather display.
Tap Menu > Orientation, and select from the following options.
Page orientation label changes to reflect the selected orientation.
North Up Track Up Heading Up
Orients page to True
north
Orients page to curren
t
aircraft GPS track
Orients page to current
aircraft heading
(requires heading data
source interface)
Banner Information
• Pan mode symbol
• Bearing and distance to map
pointer from aircraft’s
current position
WX Info Banner
Ownship Icon
Position & Orientation
• The tip represents actual
aircraft location
• Symbol type is dependent
upon configuration
• This feature is absent if a GPS
source is not available
