Garmin Pilot for iOS User’s Guide
190-01501-00 Rev. F
114
Fly
OverviewPlanFileFlySubscriptionsAppendicesIndex
SPLIT-SCREEN (PANEL)
The Panel is only available in split-screen and may be configured to show navigation
parameters and virtual gauges in one of four selectable views. Panel configuration
selection button/indicators are located at the bottom right of the panel.
Viewing the Panel:
1)
From any page touch > .
2)
Touch > Split-screen > Panel.
3)
Select one of the four panel views options.
4)
Touch to hide the Panel.
Configuring the Panel:
1)
From any page touch > .
2)
Touch > Split-screen > Panel.
3)
Select one of the three panel options with Navigation Data Fields.
4)
Touch any one of the fields and select one of the options from the flick-list.
Navigation Data Description
Altitude
The current GPS altitude or geometric height above Mean
Sea Level (MSL) in feet.
Bearing
The compass direction from the present position to a
destination waypoint.
Course
The magnetic direction from the last waypoint to the active
waypoint.
Cross Track Error
The distance and direction, left or right, the aircraft is from
the desired course in nautical miles.
Distance (Dest)
The distance to the destination waypoint in the Active Flight
Plan
Distance (Next)
The distance to the next waypoint in the Active Flight Plan.
To Next Page
