3 ft/sec (1m/s) 3 ft/sec (1m/s)
approx. 1”
3
Quick Start Steps
1
3
2
1. Power ON.
Press and release the ON / OFF Power button. The Apex powers on in the last mode used and is
ready to search. The detector operates on built-in lithium ion rechargeable batteries.
2. Select Mode.
Use the Mode button to select a dierent detection mode, when desired.
3. Adjust settings.
Press Menu Button to adjust Sensitivity, Volume, Iron Volume, Frequency, Channel, Backlight, or Z-Lynk
settings, if desired.
4. Ground Balance (if necessary).
Press and hold GND BAL button while bouncing coil above the ground.
5. Begin scanning.
Lower the searchcoil to about one inch (2.5cm) above the ground and scan the coil left and right at
approximately 3 feet/second (1 meter/second). The coil must be in motion for target detection, but can
remain stationary during Pinpoint.
4
