GAS GAS MC-E 5 - 7 Multifunctional Element; Ride Mode Button

7 MULTIFUNCTIONAL ELEMENT
18
7.1 Multifunctional element
The multifunctional element is mounted in front of the seat.
402132-10
Overview of multifunctional element
1
Ride mode button ( p. 18)
2
Ride mode display ( p. 19)
3
Malfunction indicator lamp ( p. 19)
4
Charging level indicator ( p. 19)
7.2 Ride mode button
402133-10
The ride mode button
1
determines the ride mode ( p. 19).
The ride mode button is only active if the
magnetic switch under the seat ( p. 16) is mounted.
Possible states
• The vehicle is in standby mode – The ride mode button is active.
• The vehicle is in ready mode – The ride mode button is active.
• All other vehicle conditions – The ride mode button is not active.
