13 SERVICE WORK ON THE CHASSIS
50
13.15 Installing the start number plate
M01848-10
– Attach the start number plate to the brake line.
– Position the start number plate.
Holding lugs
1
engage in the fender.
M01849-10
–
Mount and tighten screw
2
.
Guideline
Screw, start number
plate
M6 4 Nm (3 lbf ft)
13.16 Removing front fender
M01851-10
–
Remove screws
1
. Take off the front fender.
13.17 Installing front fender
M01850-10
–
Position the fender with drill holes
1
in the holding lugs on the
start number plate.
