21 TECHNICAL DATA
88
21.1 Engine
Design Brushless DC motor
Nominal power 2 kW (3 hp)
Maximum electric power 5 kW (7 hp)
Recuperation available in ride mode 3 and 6
Maximum torque depending on ride mode approx.
Ride mode 1 6 Nm (4.4 lbf ft)
Ride mode 2 9 Nm (6.6 lbf ft)
Ride mode 3 10.5 Nm (7.74 lbf ft)
Ride mode 4 12 Nm (8.9 lbf ft)
Ride mode 5 13.8 Nm (10.18 lbf ft)
Ride mode 6 13.8 Nm (10.18 lbf ft)
Theoretical maximum speed (unloaded)
Ride mode 1 12 km/h (7.5 mph)
Ride mode 2 21 km/h (13 mph)
Ride mode 3 50 km/h (31.1 mph)
Ride mode 4 71 km/h (44.1 mph)
Ride mode 5 73 km/h (45.4 mph)
Ride mode 6 73 km/h (45.4 mph)
Maximum motor speed 6,000 rpm
Cooling Air cooling
21.2 Chassis
Frame Central tube frame of chrome molybdenum steel tubing,
powder-coated
Fork WP XACT 5235
Shock absorber WP XACT 5735
Suspension travel
front 205 mm (8.07 in)
rear 185 mm (7.28 in)
Fork offset 22 mm (0.87 in)
Brake system
front Disc brake with 4-piston brake caliper
rear Disc brake with 2-piston brake caliper
Brake disc diameters
front 160 mm (6.3 in)
rear 160 mm (6.3 in)
Brake discs - wear limits
front 2.2 mm (0.087 in)
rear 2.2 mm (0.087 in)
Offroad tire pressure
front 1.0 bar (15 psi)
rear 1.0 bar (15 psi)
Secondary drive ratio 08:46
Chain 1/2 x 3/16”
Rear sprockets available 45, 46, 47
