13.6 Installing the fork protector
M01841-11
– Position the fork protector on the left and right fork leg. Mount and
tighten screws
1
.
Guideline
Remaining screws,
chassis
M6 10 Nm (7.4 lbf ft)
– Position the brake line and the clamp. Mount and tighten
screws
2
.
Guideline
Screw, brake line
clamp on fork
protector
EJOT PT
®
K60x20‑AL
2 Nm (1.5 lbf ft)
13.7 Removing the fork legs
Preparatory work
–
Raise the motorcycle with a lift stand. ( p. 42)
–
Remove the front wheel. ( p. 73)
M01840-10
Main work
–
Remove screws
1
and take off the clamp.
–
Remove screws
2
and take off the brake caliper.
–
Allow the brake caliper and the brake line to hang loosely to the
side.
Info
Do not kink the brake line.
M01842-10
– Note the installation position of the fork legs.
–
Loosen screws
3
. Remove the left fork leg.
–
Loosen screws
4
. Remove the right fork leg.
13.8 Installing the fork legs
F02179-10
Condition
Individual installation position
– Position the fork legs.
Guideline
Observe the position determined during removal.
Bleeder screws
1
are positioned toward the rear.
Condition
Standard installation position
– Position the fork legs.
Bleeder screws
1
are positioned toward the rear.
