21 TECHNICAL DATA
90
21.6 Shock absorber
Shock absorber article number 03.18.7U.02
Shock absorber WP XACT 5735
Low-speed compression damping
Comfort 18 clicks
Standard 15 clicks
Sport 12 clicks
High-speed compression damping
Comfort 2.5 turns
Standard 2 turns
Sport 1.5 turns
Rebound damping
Comfort 17 clicks
Standard 15 clicks
Sport 13 clicks
Spring preload 3 mm (0.12 in)
Spring rate
Weight of rider: 15 … 25 kg (33 … 55 lb.) 25 N/mm (143 lb/in)
Weight of rider (standard): 25 … 35 kg (55 … 77 lb.) 30 N/mm (171 lb/in)
Weight of rider: 35 … 45 kg (77 … 99 lb.) 35 N/mm (200 lb/in)
Spring length 130 mm (5.12 in)
Gas pressure 10 bar (145 psi)
Static sag 12 mm (0.47 in)
Riding sag 80 mm (3.15 in)
Fitted length 275 mm (10.83 in)
Shock absorber oil Shock absorber fluid (SAE 2.5)
(50180751S1) ( p. 93)
21.7 Chassis tightening torques
Screw, brake line clamp on fork pro-
tector
EJOT PT
®
K60x20‑AL 2 Nm (1.5 lbf ft)
Screw, brake line clamp on link fork EJOT SF
®
M5x10‑K 2 Nm (1.5 lbf ft)
Screw, magnetic switch on handlebar M3 0.8 Nm (0.59 lbf ft)
Spoke nipple M3.5 3 Nm (2.2 lbf ft)
Screw, fixed grip M4 5 Nm (3.7 lbf ft)
Loctite
®
243™
Screw, throttle grip M4 3 Nm (2.2 lbf ft)
Remaining nuts, chassis M5 5 Nm (3.7 lbf ft)
Remaining screws, chassis M5 5 Nm (3.7 lbf ft)
Screw, brake assembly M5 5 Nm (3.7 lbf ft)
Screw, brake linings M5 8 Nm (5.9 lbf ft)
Nut, push rod ball joint on foot brake
cylinder
M6 10 Nm (7.4 lbf ft)
Nut, push rod, foot brake lever M6 6 Nm (4.4 lbf ft)
Rear fairing screw M6 8 Nm (5.9 lbf ft)
Remaining nuts, chassis M6 10 Nm (7.4 lbf ft)
