TECHNICAL DATA 21
89
Steering head angle 66°
Wheelbase 1,032 ± 10 mm (40.63 ± 0.39 in)
Seat height unloaded 615 … 665 mm (24.21 … 26.18 in)
Ground clearance unloaded 207 … 252 mm (8.15 … 9.92 in)
Ready-to-ride weight approx. 40.5 kg (89.3 lb.)
21.3 Electrical system
Air-cooled lithium-ion battery
(Powerpack LV)
45445053200 Voltage (nominal): 43.2 V
Capacity: 907 Wh
Approx. charging time, 0% to 80%:
45 min
Approx. charging time, 0% to 100%:
70 min
Maintenance-free
Battery charger for Powerpack LV 45429074000 Nominal voltage: 100 … 240 V
Grid frequency: 50 … 60 Hz
Power: 900 W
21.4 Tires
Front tire Rear tire
60/100 - 12 36M TT
MAXXIS MAXX CROSS SI
2.75 - 10 38J TT
MAXXIS MAXX CROSS SI
The tires specified represent one of the possible series production tires. Additional information is available in the Service
section under:
http://www.gasgas.com
21.5 Fork
Fork article number 07.18.6U.02
Fork WP XACT 5235
Rebound damping
Comfort 15 clicks
Standard 12 clicks
Sport 10 clicks
Air pressure 2 bar (29 psi)
Fork length 685 mm (26.97 in)
Spring length with preload spacer(s) 337.5 mm (13.287 in)
Oil capacity external mechanism left 25 ± 5 ml (0.85 ± 0.17 fl. oz.) Fork oil (SAE 4) (48601166S1)
( p. 93)
Oil capacity, right cartridge 225 ml (7.61 fl. oz.) Fork oil (SAE 4) (48601166S1)
( p. 93)
Grease capacity, left cartridge 6 g (0.21 oz) Special grease (00062010053)
( p. 94)
