USB ports Plug USB (Universal Serial Bus) devices
(such as a USB printer, scanner, camera,
keyboard, or mouse) into these ports. For
more information, see “Installing a printer,
scanner, or other device” on page 30.
S/PDIF output jack
(optional)
Plug an optical cable from an amplifier or
entertainment system into this jack for
digital sound.
Microphone jack
(pink plug)
Plug a microphone into this jack.
Headphone/analog
speakers jack (green
plug)
-OR-
Front speakers jack
This jack is user configurable for one of the
following:
Headphone: Plug headphones or amplified
speakers into this jack (Default).
Stereo out: Plug your front left and right
speakers into this jack.
For more information, see “Configuring the
audio jacks” on page 30.
Wireless network
antenna (optional)
and connectors
Connect this antenna to your wireless
network antenna card.
Case cover
thumbscrew
Remove this screw before opening the case.
PS/2 mouse port Plug a PS/2 mouse into this port.
Monitor (VGA) port Plug a VGA (blue connector) monitor cable
into this port.
IEEE 1394 port Plug IEEE 1394 (also known as Firewire
™
)
devices (such as a digital camcorder) into
this 6-pin IEEE 1394 port. For more
information, see “Installing a printer,
scanner, or other device” on page 30.
Ethernet (network)
jack
Plug an Ethernet network cable or a device
(such as a DSL or cable modem for a
broadband Internet connection) into this
jack. For more information, see “Learning
about the Internet” in your online User
Guide.
Center/subwoofer
jack (orange plug)
(optional)
Plug your center speaker and subwoofer
into this jack. For more information, see
“Configuring the audio jacks” on page 30.
Component Icon Description
8512980.book Page 9 Thursday, March 6, 2008 1:30 PM
