www.gateway.com
51
8 If this is a new heat sink, remove the strip on the heat
sink that covers the gray thermal grease. If you are
re-using a heat sink, use rubbing (isopropyl) alcohol to
remove the old thermal grease, then re-apply a small
bead of thermal grease (about the size of a pea) to the
surface that contacts the processor.
9 Place the heat sink and fan assembly on the processor,
then tighten the screws that secure it to the system
board.
10 Connect the heat sink fan cable to the system board.
11 Replace the side panel by following the instructions in
“Replacing the side panel” on page 38.
Adding or replacing an
expansion card
To add or replace an expansion card:
1 Remove the side panel by following the instructions in
“Removing the side panel” on page 35.
2 If you are replacing an expansion card, disconnect any
cables that are attached to the card, noting their
locations and orientation. (You may need to reconnect
the cables after you install the new card.)
3 Open the card retention lever.
8512980.book Page 51 Thursday, March 6, 2008 1:30 PM
