CHAPTER 4: Upgrading Your Computer
52
4 If you are replacing an expansion card, remove the old
card. You can slightly seesaw the card end-to-end to
loosen the card, but do not bend the card sideways.
5 Install the new card into the expansion slot. You can
slightly seesaw the card end-to-end to help insert the
card, but do not bend the card sideways.
6 If you have just replaced an expansion card, reconnect
the expansion card cables (if any) using your notes from
Step 2. If you have added a new expansion card, connect
its cables according to its user guide.
7 Press the card retention lever back into place.
8 Replace the side panel by following the instructions in
“Replacing the side panel” on page 38.
Caution
Do not touch the contacts on the bottom part of the expansion
card. Touching the contacts can cause electrostatic damage to the card.
8512980.book Page 52 Thursday, March 6, 2008 1:30 PM
