CHAPTER 2: Checking Out Your Computer
8
Back
Important
Your computer’s hardware options and port locations may vary from this
illustration.
Component Icon Description
Voltage switch The switch is preset at the factory. Make
sure that this is set to the correct voltage for
your area.
Power connector Plug the power cord into this connector.
PS/2 keyboard port Plug a PS/2 keyboard into this port.
PS/2 mouse port
PS/2 keyboard port
Voltage switch
Power connector
Ethernet (network) jack
Audio in/side speaker jack
Case cover thumbscrew
Headphone/front
speaker jack
Mic jack
Surround L/R speaker jack
Center/subwoofer jack
USB ports
Video card (optional)
Wireless network antenna connectors
IEEE 1394 port
TV tuner card (optional)
Case cover thumbscrew
S/PDIF jack
(optional)
Monitor (VGA) port
Wireless network antenna (optional)
Audio card (optional)
8512980.book Page 8 Thursday, March 6, 2008 1:30 PM
