www.gateway.com
73
10 Remove the seven system board screws.
11 Lift the system board up and out of the case.
12 Align the new system board on the standoffs and secure
it into the computer case with the screws.
13 If your replacement system board does not include a
processor, go to Step 14.
-OR-
If your replacement system board includes a processor,
go to Step 17.
14 Release the processor from the old system board by
pushing down on the lever, then lifting the lever
completely up.
15 Remove the processor from the old system board.
Screws Screws
8511858.book Page 73 Monday, December 18, 2006 10:51 AM
