www.gateway.com
45
Opening the case
Your computer case provides easy access to internal
components.
Removing the left side panel
To remove the left side panel:
1 Follow the instructions in “Preventing static electricity
discharge” on page 44.
2 Shut down your computer, then disconnect the power
cord and modem, network, and all peripheral device
cables.
3 Press the power button for ten seconds to drain any
residual power from your computer.
4 Remove the security tape (if any) on the rear edge of the
side panel.
5 Remove the two Phillips hex screws on the back edge of
the left side panel. For their location, see “Back” on
page 9.
6 Slide the side panel toward the back of your computer,
then pull the panel away from your computer.
Warning
To avoid exposure to dangerous electrical voltages and moving parts, turn
off your computer, then unplug the power cord and modem cable before opening
the case.
8513217.book Page 45 Wednesday, August 27, 2008 3:30 PM
