GATEXPERT SW400DC - Table 1 Recommended Installation Position

Instructions for SW400DC
www.gatexpertstore.com
8
Installation direction: door opens inward
B
C
A
D
L
F
E
Note:Note: TheThe unlimitedunlimited versionversion
mustmust havehave a limitlimit stopperstopper
installedinstalled
ItIt isis recommendedrecommended toto installinstall withwith a
safetysafety stopperstopper (should(should bebe
preparedprepared byby thethe usersusers themselves)themselves)
Figure 8
A(mm)
B(mm)
C(mm)
D max
L(mm)
SIZE
240
115
15
100°
1400
220
125
25
100°
1440
200
135
35
100°
1420
180
145
45
90°
1420
Table 1 Recommended Installation Position
