GATEXPERT SW400DC - Table 2 Recommended Installation Position

Instructions for SW400DC
www.gatexpertstore.com
9
Installation direction: door opens outward
L
A
B
F
E
D
C
Note:Note: TheThe unlimitedunlimited versionversion
mustmust havehave a limitlimit stopperstopper
installedinstalled
ItIt isis recommendedrecommended toto installinstall withwith a
safetysafety stopperstopper (should(should bebe
preparedprepared byby thethe usersusers themselves)themselves)
Figure 9
A(mm)
B(mm)
C(mm)
D max
L(mm)
SIZE
170
170
40
90°
1000
180
170
30
100°
1000
190
170
30
100°
1000
200
180
40
100°
1000
Table 2 Recommended Installation Position
Note: Value B must be close or equal to the value A to reach the best
mechanical advantage.
