Expert 52 User Manual
Installation
2-3
Step 3
Place the stand beam upright on the T-stand and put the screws into the holes but do not
tighten them at this step.
Step 4
Remove the cutting plotter from the carton. Position the stand under the plotter, and insert the
screws into the holes on the bottom of the plotter and tighten them up as shown in Figure 2-3.
T-stand
Stand Beam
Figure 2-2
Figure 2-3
