Laser Tube Model Page
The Laser Tube Model Page allows you to correctly indicate the laser installed on the machine in case
of laser upgrades or if required after a machine reset.
• C_12/C_30V/C_40
Laser Tube Model Page
Relevant Buttons Function
/
Directional No action
/
Directional Scroll between selections
Enter Select indicated option
Menu
Go to Menu Page
A/F
Initiate the auto focus function
A/F ▲ / ▼ Directional
Manually adjust the height of the work table (Z-axis)
Start / Pause Go to Main Work page
Stop Go to Main Work page
Back Go to previous screen
Light Turn Light On/Off
Carriage / Work Table
Adjustment Page
Main Work Page
Menu Page
Press Menu
Navigating to this page:
Advanced Setting Page
Select < Advanced
Setting > from the
menu
Laser Tube Model Page
Select < Laser Tube
Model > from the
menu
To Next Page
