Machine Setting Page
The Machine Setting Page allows you to access and modify various machine settings, including:
Set Lens, Tune Auto Focus, Set Table Down, Carriage Free, Set Command Mode, File Save
Mode, Scaling, Other, and Reset.
Machine Setting Page
Relevant Buttons Function
F1 (Back) Back to previous page
U / V Directional Scroll through your loaded jobs
Enter Perform the selection
Start / Stop Back to Main Work Page
Auto Focus Initiate the auto focus function
S / T Manual Focus Buttons
Manually adjust the height of the work table (Z-
axis)
Main Work Page
Functions Page
Navigating to this page:
To Next Page
