5–58 745 TRANSFORMER PROTECTION SYSTEM – INSTRUCTION MANUAL
S4 ELEMENTS CHAPTER 5: SETPOINTS
FIGURE 5–14: Instantaneous differential scheme logic
5.6.5 Phase Overcurrent
5.6.5.1 Main menu
PATH: SETPOINTS  S4 ELEMENTS  PHASE OC
 PHASE OC []  W1 PHASE []
TIME OC
See page 5–63
MESSAGE
 W2 PHASE []
TIME OC
See page 5–63
MESSAGE
 W3 PHASE []
TIME OC
See page 5–63
MESSAGE
 W1 PHASE []
INST OC 1
See page 5–65
MESSAGE
 W2 PHASE []
INST OC 1
See page 5–65
MESSAGE
 W3 PHASE []
INST OC 1
See page 5–65
MESSAGE
 W1 PHASE []
INST OC 2
See page 5–65
MESSAGE
 W2 PHASE []
INST OC 2
See page 5–65
MESSAGE
 W3 PHASE []
INST OC 2
See page 5–65
