6.4 A3 Event Recorder
6.4.1 Event Data Clear
PATH: ACTUAL VALUES  A3 EVENT RECORDER  EVENT DATA CLEAR
Enter “Yes” for the CLEAR EVENT DATA RECORDER to clear all event recorder data. The
CLEAR EVENT RECORDER SIGNAL actual value assigns a logic input to be used for remote
clearing of the event recorder. The last date and time the event data were cleared are also
displayed. If the date has never been programmed, the default values shown above
appear.
6.4.2 Event Records
PATH: ACTUAL VALUES  A3 EVENT RECORDER  EVENT 001(256)
 EVENT DATA []
CLEAR
CLEAR EVENT DATA
RECORDER? No
MESSAGE
CLEAR EVENT RECORDER
SIGNAL: Disabled
MESSAGE
DATE OF LAST CLEAR:
Jan 01 1996
MESSAGE
TIME OF LAST CLEAR:
00:00:00.000
MESSAGE
NO. OF EVENTS SINCE
LAST CLEAR: 0
 EVENT 001 [] EVENT DATE:
Jan 01 2001
MESSAGE
EVENT TIME:
00:00:00:000
MESSAGE
EVENT CAUSE: On
Control Power
MESSAGE
W1 PHASE A CURRENT
0 A at 0° Lag
MESSAGE
W1 PHASE B CURRENT
0 A at 0° Lag
MESSAGE
W1 PHASE C CURRENT
0 A at 0° Lag
MESSAGE
W1 GROUND CURRENT
0 A at 0° Lag
MESSAGE
W1 (% ƒo) H2a: 0.0
H2b: 0.0 H2c: 0.0
MESSAGE
W1 (% ƒo) H5a: 0.0
H5b: 0.0 H5c: 0.0
MESSAGE
W2 PHASE A CURRENT
0 A at 0° Lag
