6.3.11.2 Energy Data Clear
PATH: ACTUAL VALUES
 A2 METERING  ENERGY  ENERGY DATA CLEAR
To clear all energy data, set
CLEAR ENERGY DATA to “Yes”. The last date and time that the
energy data were cleared are also displayed. If the date has never been programmed, the
default values shown above appear.
6.3.11.3 Windings 1 to 3 Energy
PATH: ACTUAL VALUES
 A2 metering  ENERGY  W1(3) ENERGY
The source and load watthours and varhours are displayed for winding 1. These messages
are repeated for windings 2 and 3.
 ENERGY DATA []
CLEAR
CLEAR ENERGY
DATA? No
MESSAGE
DATE OF LAST CLEAR:
Jan 01 1996
MESSAGE
TIME OF LAST CLEAR:
00:00:00
 W1 ENERGY [] W1 SOURCE WATTHOURS:
0 MWh
MESSAGE
W1 LOAD WATTHOURS:
0 MWh
MESSAGE
W1 SOURCE VARHOURS:
0 Mvarh
MESSAGE
W1 LOAD VARHOURS:
0 Mvarh
