3300/25 Dual Accelerometer Input Monitor Operation Manual
16
7.3 Signal Input Relay Module Removal
High voltage present. Contact
could cause shock, burns, or death.
Do not touch exposed wires or
terminals.
Machine protection provided by
this monitor will be lost while the
Signal Input Relay Module is
removed from the rack.
Module Removal
Loosen two screws and remove
the module.
The Signal Input Relay Module is on
the back of the rack. For relay
configuration, see the System
Installation Instructions manual. For
field wiring, refer to 3300/25 Field
Wiring Diagram Packet.
