IEC 61850 messaging can form part of protection schemes. Consider 61850 settings with the same criticality as
protection element settings. To ensure reliable performance of protection schemes utilizing 61850 messaging, it
can be desirable to route 61850 traffic on a separate port from SCADA communications, or to use redundant, inde-
pendent ports, and a high speed network recovery method, such as PRP.
The C30 supports the Manufacturing Message Specification (MMS) protocol as specified by IEC 61850. MMS is supported
over two protocol stacks: TCP/IP over Ethernet. The C30 operates as an IEC 61850 server. The Remote inputs and outputs
section in this chapter describe the peer-to-peer GSSE/GOOSE message scheme.
The GSSE/GOOSE configuration main menu is divided into two areas: transmission and reception.
PATH: SETTINGS  PRODUCT SETUP  COMMUNICATIONS  IEC 61850 PROTOCOL  GSSE/GOOSE CONFIGURATION
The main transmission menu is shown below:
PATH: SETTINGS  PRODUCT SETUP  COMMUNICATIONS  IEC 61850 PROTOCOL  GSSE/GOOSE CONFIGURATION
 TRANSMISSION
The general transmission settings are shown below:
PATH: SETTINGS  PRODUCT SETUP  COMMUNICATIONS  IEC 61850 PROTOCOL  GSSE/GOOSE CONFIGURATION
 TRANSMISSION  GENERAL
The DEFAULT GSSE/GOOSE UPDATE TIME sets the time between GSSE or GOOSE messages when there are no remote out-
put state changes to be sent. When remote output data changes, GSSE or GOOSE messages are sent immediately. This
setting controls the steady-state heartbeat time interval.
The
DEFAULT GSSE/GOOSE UPDATE TIME setting is applicable to GSSE, fixed C30 GOOSE, and configurable GOOSE.
The GSSE settings are shown below:
PATH: SETTINGS  PRODUCT SETUP  COMMUNICATIONS  IEC 61850 PROTOCOL  GSSE/GOOSE CONFIGURATION
 TRANSMISSION  GSEE
These settings are applicable to GSSE only. If the fixed GOOSE function is enabled, GSSE messages are not transmitted.
 GSSE / GOOSE
 CONFIGURATION
 TRANSMISSION

MESSAGE
 RECEPTION

 TRANSMISSION

 GENERAL

MESSAGE
 GSSE

MESSAGE
 FIXED GOOSE

MESSAGE
 CONFIGURABLE
 GOOSE
 GENERAL

DEFAULT GSSE/GOOSE
UPDATE TIME: 60 s
Range: 1 to 60 s in steps of 1
 GSSE

GSSE FUNCTION:
Enabled
Range: Enabled, Disabled
MESSAGE
GSSE ID:
GSSEOut
Range: 65-character ASCII string
MESSAGE
DESTINATION MAC:
000000000000
Range: standard MAC address
