B-36 C30 Controller System GE Multilin
B.4 MEMORY MAPPING APPENDIX B
B
A3A0 ...Repeated for Digital Counter 5
A3C8 ...Repeated for Digital Counter 6
A3F0 ...Repeated for Digital Counter 7
A418 ...Repeated for Digital Counter 8
PID Regulator (Read/Write Setting) (4 modules)
A500 PID 1 Function 0 to 1 --- 1 F102 0 (Disabled)
A501 PID 1 Sample Time 0.05 to 30 sec 0.01 F001 5
A502 PID 1 Process Signal 0 to 65535 --- 1 F600 0
A503 PID 1 Setpoint Signal -99999.99 to 99999.99 --- 0.01 F004 0
A505 PID 1 Tracking Signal 0 to 65535 --- 1 F600 0
A506 PID 1 Proportional Gain 0.01 to 100 --- 0.01 F001 100
A507 PID 1 Setpoint Weighting 0.01 to 1 --- 0.01 F001 100
A508 PID 1 Integ Time Const 0 to 600 sec 0.01 F001 100
A509 PID 1 Antiwindup 0 to 1 --- 1 F102 0 (Disabled)
A50A PID 1 AW Time Const 0 to 600 sec 0.01 F001 100
A50B PID 1 Deriv Time Const 0 to 600 sec 0.01 F001 100
A50C PID 1 Derivative Limit 1 to 20 --- 1 F001 10
A50D PID 1 Max -10000 to 10000 --- 1 F002 10
A50E PID 1 Min -10000 to 10000 --- 1 F002 10
A50F PID 1 T Min 100 to 9999 ms 1 F001 500
A510 PID 1 Dead Time 1 to 20 sec 1 F001 1
A511 PID 1 Block 0 to 4294967295 --- 1 F300 0
A513 PID 1 Target 0 to 2 --- 1 F109 0 (Self-reset)
A514 PID 1 Events 0 to 1 --- 1 F102 0 (Disabled)
A515 ...Repeated for PID 2
A52A ...Repeated for PID 3
A53F ...Repeated for PID 4
PID Regulator Actuals (Read Only) (4 modules)
A560 PID 1 Out 0 to 999999 --- 1 F004 0
A562 PID 1 Delta Out 0 to 999999 --- 1 F004 0
A564 PID 1 Setpoint -99999.99 to 99999.99 --- 0.01 F004 0
A566 ...Repeated for PID 2
A56C ...Repeated for PID 3
A572 ...Repeated for PID 4
Non Volatile Latches (Read/Write Setting) (16 modules)
A700 Non-Volatile Latch 1 Function 0 to 1 --- 1 F102 0 (Disabled)
A701 Non-Volatile Latch 1 Type 0 to 1 --- 1 F519 0 (Reset
Dominant)
A702 Non-Volatile Latch 1 Set 0 to 4294967295 --- 1 F300 0
A704 Non-Volatile Latch 1 Reset 0 to 4294967295 --- 1 F300 0
A706 Non-Volatile Latch 1 Target 0 to 2 --- 1 F109 0 (Self-reset)
A707 Non-Volatile Latch 1 Events 0 to 1 --- 1 F102 0 (Disabled)
A708 Reserved (4 items) --- --- --- F001 0
A70C ...Repeated for Non-Volatile Latch 2
A718 ...Repeated for Non-Volatile Latch 3
A724 ...Repeated for Non-Volatile Latch 4
A730 ...Repeated for Non-Volatile Latch 5
A73C ...Repeated for Non-Volatile Latch 6
A748 ...Repeated for Non-Volatile Latch 7
A754 ...Repeated for Non-Volatile Latch 8
A760 ...Repeated for Non-Volatile Latch 9
A76C ...Repeated for Non-Volatile Latch 10
A778 ...Repeated for Non-Volatile Latch 11
A784 ...Repeated for Non-Volatile Latch 12
Table B–10: MODBUS MEMORY MAP (Sheet 28 of 48)
ADDR REGISTER NAME RANGE UNITS STEP FORMAT DEFAULT
