GE Multilin C30 Controller System B-49
APPENDIX B B.4 MEMORY MAPPING
B
C900 ...Repeated for Direct Input 29
C904 ...Repeated for Direct Input 30
C908 ...Repeated for Direct Input 31
C90C ...Repeated for Direct Input 32
Direct Input/Output Alarms (Read/Write Setting)
CAD0 Direct Input/Output Channel 1 CRC Alarm Function 0 to 1 --- 1 F102 0 (Disabled)
CAD1 Direct Input/Output Channel 1 CRC Alarm Message Count 100 to 10000 --- 1 F001 600
CAD2 Direct Input/Output Channel 1 CRC Alarm Threshold 1 to 1000 --- 1 F001 10
CAD3 Direct Input/Output Channel 1 CRC Alarm Events 0 to 1 --- 1 F102 0 (Disabled)
CAD4 Reserved (4 items) 1 to 1000 --- 1 F001 10
CAD8 Direct Input/Output Channel 2 CRC Alarm Function 0 to 1 --- 1 F102 0 (Disabled)
CAD9 Direct Input/Output Channel 2 CRC Alarm Message Count 100 to 10000 --- 1 F001 600
CADA Direct Input/Output Channel 2 CRC Alarm Threshold 1 to 1000 --- 1 F001 10
CADB Direct Input/Output Channel 2 CRC Alarm Events 0 to 1 --- 1 F102 0 (Disabled)
CADC Reserved (4 items) 1 to 1000 --- 1 F001 10
CAE0 Direct Input/Output Ch 1 Unreturned Messages Alarm
Function
0 to 1 --- 1 F102 0 (Disabled)
CAE1 Direct Input/Output Ch 1 Unreturned Messages Alarm Msg
Count
100 to 10000 --- 1 F001 600
CAE2 Direct Input/Output Ch 1 Unreturned Messages Alarm
Threshold
1 to 1000 --- 1 F001 10
CAE3 Direct Input/Output Ch 1 Unreturned Messages Alarm
Events
0 to 1 --- 1 F102 0 (Disabled)
CAE4 Reserved (4 items) 1 to 1000 --- 1 F001 10
CAE8 Direct Input/Output Ch 2 Unreturned Messages Alarm
Function
0 to 1 --- 1 F102 0 (Disabled)
CAE9 Direct Input/Output Ch 2 Unreturned Messages Alarm Msg
Count
100 to 10000 --- 1 F001 600
CAEA Direct Input/Output Ch 2 Unreturned Messages Alarm
Threshold
1 to 1000 --- 1 F001 10
CAEB Direct Input/Output Channel 2 Unreturned Messages Alarm
Events
0 to 1 --- 1 F102 0 (Disabled)
CAEC Reserved (4 items) 1 to 1000 --- 1 F001 10
Remote Devices (Read/Write Setting) (32 modules)
CB00 Remote Device 1 GSSE/GOOSE Application ID (GOID) --- --- --- F209 “Remote Device
1“
CB21 Remote Device 1 GOOSE Ethernet APPID 0 to 16383 --- 1 F001 0
CB22 Remote Device 1 GOOSE Dataset 0 to 16 --- 1 F184 0 (Fixed)
CB23 Remote Device 1 in PMU Scheme 0 to 1 --- 1 F126 0 (No)
CB24 Reserved 0 to 3 --- 1 F626 0 (None)
CB25 ...Repeated for Device 2
CB4A ...Repeated for Device 3
CB6F ...Repeated for Device 4
CB94 ...Repeated for Device 5
CBB9 ...Repeated for Device 6
CBDE ...Repeated for Device 7
CC03 ...Repeated for Device 8
CC28 ...Repeated for Device 9
CC4D ...Repeated for Device 10
CC72 ...Repeated for Device 11
CC97 ...Repeated for Device 12
CCBC ...Repeated for Device 13
CCE1 ...Repeated for Device 14
CD06 ...Repeated for Device 15
CD2B ...Repeated for Device 16
CD50 ...Repeated for Device 17
CD75 ...Repeated for Device 18
Table B–10: MODBUS MEMORY MAP (Sheet 41 of 48)
ADDR REGISTER NAME RANGE UNITS STEP FORMAT DEFAULT
