B-50 C30 Controller System GE Multilin
B.4 MEMORY MAPPING APPENDIX B
B
CD9A ...Repeated for Device 19
CDBF ...Repeated for Device 20
CDE4 ...Repeated for Device 21
CE09 ...Repeated for Device 22
CE2E ...Repeated for Device 23
CE53 ...Repeated for Device 24
CE78 ...Repeated for Device 25
CE9D ...Repeated for Device 26
CEC2 ...Repeated for Device 27
CEE7 ...Repeated for Device 28
CF0C ...Repeated for Device 29
CF31 ...Repeated for Device 30
CF56 ...Repeated for Device 31
CF7B ...Repeated for Device 32
Remote Inputs (Read/Write Setting) (64 modules)
CFA0 Remote Input 1 Device 1 to 32 --- 1 F001 1
CFA1 Remote Input 1 Bit Pair 0 to 96 --- 1 F156 0 (None)
CFA2 Remote Input 1 Default State 0 to 3 --- 1 F086 0 (Off)
CFA3 Remote Input 1 Events 0 to 1 --- 1 F102 0 (Disabled)
CFA4 Remote Input 1 Name 1 to 64 --- 1 F205 “Rem Ip 1”
CFAA ...Repeated for Remote Input 2
CFB4 ...Repeated for Remote Input 3
CFBE ...Repeated for Remote Input 4
CFC8 ...Repeated for Remote Input 5
CFD2 ...Repeated for Remote Input 6
CFDC ...Repeated for Remote Input 7
CFE6 ...Repeated for Remote Input 8
CFF0 ...Repeated for Remote Input 9
CFFA ...Repeated for Remote Input 10
D004 ...Repeated for Remote Input 11
D00E ...Repeated for Remote Input 12
D018 ...Repeated for Remote Input 13
D022 ...Repeated for Remote Input 14
D02C ...Repeated for Remote Input 15
D036 ...Repeated for Remote Input 16
D040 ...Repeated for Remote Input 17
D04A ...Repeated for Remote Input 18
D054 ...Repeated for Remote Input 19
D05E ...Repeated for Remote Input 20
D068 ...Repeated for Remote Input 21
D072 ...Repeated for Remote Input 22
D07C ...Repeated for Remote Input 23
D086 ...Repeated for Remote Input 24
D090 ...Repeated for Remote Input 25
D09A ...Repeated for Remote Input 26
D0A4 ...Repeated for Remote Input 27
D0AE ...Repeated for Remote Input 28
D0B8 ...Repeated for Remote Input 29
D0C2 ...Repeated for Remote Input 30
D0CC ...Repeated for Remote Input 31
D0D6 ...Repeated for Remote Input 32
D0E0 ...Repeated for Remote Input 33
D0EA ...Repeated for Remote Input 34
D0F4 ...Repeated for Remote Input 35
Table B–10: MODBUS MEMORY MAP (Sheet 42 of 48)
ADDR REGISTER NAME RANGE UNITS STEP FORMAT DEFAULT
