B-62 C30 Controller System GE Multilin
B.4 MEMORY MAPPING APPENDIX B
B
F157
ENUMERATION: BREAKER MODE
0 = 3-Pole, 1 = 1-Pole
F166
ENUMERATION: AUXILIARY VT CONNECTION TYPE
0 = Vn, 1 = Vag, 2 = Vbg, 3 = Vcg, 4 = Vab, 5 = Vbc, 6 = Vca
F172
ENUMERATION: SLOT LETTERS
F173
ENUMERATION: DCMA INPUT/OUTPUT RANGE
F174
ENUMERATION: TRANSDUCER RTD INPUT TYPE
0 = 100 Ohm Platinum, 1 = 120 Ohm Nickel,
2 = 100 Ohm Nickel, 3 = 10 Ohm Copper
F177
ENUMERATION: COMMUNICATION PORT
0 = None, 1 = COM1-RS485 (not applicable to UR firmware 7.00),
2 = COM2-RS485, 3 = Front Panel-RS232, 4 = Network - TCP,
5 = Network - UDP
F183
ENUMERATION: AC INPUT WAVEFORMS
F184
ENUMERATION: IEC GOOSE DATASET
23 DNA-23 58 UserSt-26
24 DNA-24 59 UserSt-27
25 DNA-25 60 UserSt-28
26 DNA-26 61 UserSt-29
27 DNA-27 62 UserSt-30
28 DNA-28 63 UserSt-31
29 DNA-29 64 UserSt-32
30 DNA-30 65 Dataset Item 1
31 DNA-31 66 Dataset Item 2
32 DNA-32 67 Dataset Item 3
33 UserSt-1 ↓↓
34 UserSt-2 96 Dataset Item 32
Bitmask Slot Bitmask Slot Bitmask Slot Bitmask Slot
0F 4K 8P 12U
1G 5 L 9R 13V
2H 6M 10S 14W
3J 7N 11T 15X
Bitmask DCmA input/output range
0 0 to –1 mA
1 0 to 1 mA
2 –1 to 1 mA
3 0 to 5 mA
4 0 to 10 mA
5 0 to 20 mA
6 4 to 20 mA
Bitmask Value Bitmask Value
Bitmask Definition
0Off
1 8 samples/cycle
2 16 samples/cycle
3 32 samples/cycle
4 64 samples/cycle
Value IEC 61850 dataset
0Off
1 GooseIn 1
2 GooseIn 2
3 GooseIn 3
4 GooseIn 4
5 GooseIn 5
6 GooseIn 6
7 GooseIn 7
8 GooseIn 8
9 GooseIn 9
10 GooseIn 10
11 GooseIn 11
12 GooseIn 12
13 GooseIn 13
14 GooseIn 14
15 GooseIn 15
16 GooseIn 16
