GE C30 User Manual

GE Multilin C30 Controller System B-63
APPENDIX B B.4 MEMORY MAPPING
B
F190
ENUMERATION: SIMULATED KEYPRESS
F192
ENUMERATION: ETHERNET OPERATION MODE
0 = Half-Duplex, 1 = Full-Duplex
F194
ENUMERATION: DNP SCALE
0 = 0.01, 1 = 0.1, 2 = 1, 3 = 10, 4 = 100, 5 = 1000, 6 = 10000,
7 = 100000, 8 = 0.001
F200
TEXT40: 40-CHARACTER ASCII TEXT
20 registers, 16 Bits: 1st Char MSB, 2nd Char LSB
F202
TEXT20: 20-CHARACTER ASCII TEXT
10 registers, 16 Bits: 1st Char MSB, 2nd Char LSB
F203
TEXT16: 16-CHARACTER ASCII TEXT
F204
TEXT80: 80-CHARACTER ASCII TEXT
F205
TEXT12: 12-CHARACTER ASCII TEXT
F206
TEXT6: 6-CHARACTER ASCII TEXT
F207
TEXT4: 4-CHARACTER ASCII TEXT
F209
TEXT65: 65-CHARACTER ASCII TEXT
F213
TEXT32: 32-CHARACTER ASCII TEXT
F220
ENUMERATION: PUSHBUTTON MESSAGE PRIORITY
F232
ENUMERATION: CONFIGURABLE GOOSE Tx
DATASET ITEMS
Bitmask Keypress Bitmask Keypress
0 No key ---
use between real keys
23 Reset
24 User 1
1 1 25 User 2
2 2 26 User 3
3 3 27 User-programmable key 1
4 4 28 User-programmable key 2
5 5 29 User-programmable key 3
6 6 30 User-programmable key 4
7 7 31 User-programmable key 5
8 8 32 User-programmable key 6
9 9 33 User-programmable key 7
10 0 34 User-programmable key 8
11 Decimal Point 35 User-programmable key 9
12 Plus/Minus 36 User-programmable key 10
13 Value Up 37 User-programmable key 11
14 Value Down 38 User-programmable key 12
15 Message Up 39 User 4 (control pushbutton)
16 Message Down 40 User 5 (control pushbutton)
17 Message Left 41 User 6 (control pushbutton)
18 Message Right 42 User 7 (control pushbutton)
19 Menu 43 User-programmable key 13
20 Help 44 User-programmable key 14
21 Escape 45 User-programmable key 15
22 Enter 46 User-programmable key 16
Value Priority
0 Disabled
1Normal
2 High Priority
Value IEC 61850 Tx dataset item
0None
1 GGIO1.ST.Ind1.q
2 GGIO1.ST.Ind1.stVal
3 GGIO1.ST.Ind2.q
4 GGIO1.ST.Ind2.stVal
↓↓
255 GGIO1.ST.Ind128.q
256 GGIO1.ST.Ind128.stVal
257 MMXU1.MX.TotW.mag.f
258 MMXU1.MX.TotVAr.mag.f
259 MMXU1.MX.TotVA.mag.f
260 MMXU1.MX.TotPF.mag.f
261 MMXU1.MX.Hz.mag.f
262 MMXU1.MX.PPV.phsAB.cVal.mag.f
263 MMXU1.MX.PPV.phsAB.cVal.ang.f
264 MMXU1.MX.PPV.phsBC.cVal.mag.f
265 MMXU1.MX.PPV.phsBC.cVal.ang.f
266 MMXU1.MX.PPV.phsCA.cVal.mag.f
267 MMXU1.MX.PPV.phsCA.cVal.ang.f
268 MMXU1.MX.PhV.phsA.cVal.mag.f
269 MMXU1.MX.PhV.phsA.cVal.ang.f
270 MMXU1.MX.PhV.phsB.cVal.mag.f
271 MMXU1.MX.PhV.phsB.cVal.ang.f
272 MMXU1.MX.PhV.phsC.cVal.mag.f
