Chapter 3: Programming
Concord 4 Installation Manual 67
Edit sensors
Shortcut: 083
Default: None
This menu lets you view and, if desired, change the group and partition
assignment for each learned zone or sensor. For example, the display
shows:
S01 P1 G13 NC HW BACK DOOR.
Where S01 is the zone/sensor number, P1 is partition 1, G13 is sensor group
13, NC is normally closed, HW is hardwired, and BACK DOOR is the
programmed text name.
Other description codes include:
• RF (wireless sensor)
• TP (touchpad)
• NO (normally open)
To edit sensors:
1. Press A or B until the display shows EDIT SENSORS.
2. Press # and the display shows the sensor or zone with the lowest number.
3. Press A or B to scroll through all learned zones and sensors.
4. When the desired zone or sensor is displayed, press #. The display shows
SENSOR PTN n (current partition assignment).
5. Enter the desired partition number, then press #. The display shows the
new partition assignment.
6. Press A or B and the display shows SENSOR GROUP nn (current group
assignment).
7. Enter the desired group number, then press #. The display shows the new
group assignment.
