Chapter 3: Programming
74 Concord 4 Installation Manual
Output text
Shortcut: 10120 to
10123
Default: None
Entering text for an output allows the user to control it directly or by
schedule. Use the following guidelines to name SnapCard outputs:
• Use the item numbers that appear in
Table 25 on page 128 for characters
and words listed there.
• If you want an output for user output control, you must use the output text
feature to name the output. If no output text is programmed, the user will
not have access to the output.
• When using words from
Table 25 on page 128, spaces between them
appear automatically. When using characters from the table to create
words, you must reserve an item number for a space after the word.
• Each character or word uses one item number. For example, a word from
the list counts as one item number.
• Only 16 item numbers are allowed for each output name, so plan before
programming output text. You may need to abbreviate words to avoid
running out of item numbers.
To program output text:
1. With the display showing SNAPCARDS, press #, then A or B until the
display shows OUTPUT TEXT.
2. Press # and the display shows OUTPUT 1.
3. Press A or B until the desired output number is displayed.
4. Press # and the display shows OUTPUT N ITEM 0 0 - where ITEM 0
is the first character/word location and 0 is the character/word number.
5. Enter the number of the desired character or word, or scroll through the
numbers by pressing B (forward) or A (backward). If you make a mistake,
enter the correct number or continue scrolling through choices.
6. Press # to accept the displayed choice and the display shows OUTPUT N
ITEM 1 0 -.
7. Repeat the process as needed to complete the output name.
8. Press * after entering the last character or word number. The display
shows the complete text name. For example: OUTPUT 1 GARAGE DOOR.
