GE DigitalFlow XMT868i User Manual

Chapter 2. Initial Setup
32 DigitalFlow™ XMT868i Startup Guide
2.3.1c Programming Mass Flow Data
1. Scroll to the desired Mass Flow Units for flow rate display (see Table 7 below), and press [Enter].
2. Scroll to the desired Mass Flow Time Units (from seconds to days), and press
[Enter].
3. Scroll to the desired number of Decimal Digits (digits to the right of the decimal point) in the mass flow rate
display, and press
[Enter].
4. Scroll to the desired Mass Totals (units for the totalized mass flow rate display and press
[Enter].
5. Scroll to the desired number of Mass Decimal Digits (digits to the right of the decimal point) in the totalized
mass flow rate display, and press
[Enter].
The program varies, depending on whether or not you have enabled the Energy Option.
• If you have not enabled the Energy Option, the XMT868i returns to the Global PROGRAM window. Press
[Escape] to return to the PROG menu and scroll to the Channel PROGRAM.
• If you have enabled the Energy Option, continue to the next page.
Table 7: Available Mass Flow Units
English Metric
LB = Pounds KG = Kilograms
KLB = KiloPounds (Thousands of Pounds) Tonne = Metric Tons (1000 KG)
MMLB = MegaPounds
TONS (2000 LB)
