Chapter 2. Initial Setup
36 DigitalFlow™ XMT868i Startup Guide
2.4.2 Entering Data in the Channel System Option (cont.)
6. Scroll to the desired number of Vol Decimal Digits (digits to the right of the decimal point) in the volumetric
flow display, and press
[Enter].
7. Scroll to the desired Totalizer Units for the totalized flow rate display (see Table 11 below), and press
[Enter].
8. Scroll to the desired number of Decimal Digits (digits to the right of the decimal point) in the totalized flow
rate display, and press
[Enter].
The program now varies, depending on whether you have activated Mass Flow (see the Programming Manual for
details) or the Energy Option.
• If you have activated Mass Flow, continue to step 1 on the next page.
• If you have activated the Energy Option (but not Mass Flow), skip to step 1 on page 38.
• If you have activated neither option, the XMT868i returns to the Channel PROGRAM window. Proceed to the
PIPE option.
Table 11: Totalizer Units
English Metric
GAL - U.S. Gallons L - Liters
MGAL - Mega U.S. gallons ML - Megaliters
ft^3 - Cubic Feet m^3- Cubic Meters
Mft^3 - Mega Cubic Feet Mm^3- Mega Cubic Meters
BBL - Barrels BBL - Barrels
MBBL - Megabarrels MBBL - Megabarrels
AC-IN - Acre-inches
AC-FT - Acre-feet
