DigitalFlow™ XMT868i Startup Guide 37
Chapter 2. Initial Setup
2.4.2a Programming the Mass Flow Option
1. Scroll to the desired Mass Flow Units for flow rate display (see Table 12 below), and press [Enter].
2. Scroll to the desired Mass Flow Time Units (from seconds to days), and press
[Enter].
3. Scroll to the desired number of Decimal Digits (digits to the right of the decimal point) in the mass flow rate
display, and press
[Enter].
4. Scroll to the desired Mass Totals (units for the totalized mass flow rate display) and press
[Enter].
5. Scroll to the desired number of Mass Decimal Digits (digits to the right of the decimal point) in the totalized
mass flow rate display, and press
[Enter].
The program varies, depending on whether or not you have enabled the Energy Option.
• If you have not enabled the Energy Option, the XMT868i returns to the Channel PROGRAM window. Proceed
to the
PIPE option.
• If you have enabled the Energy Option, continue to the next page.
Table 12: Available Mass Flow Units
English Metric
LB = Pounds Kilograms
KLB = KiloPounds (Thousands of Pounds) Tonnes = Metric Tons (1000 KG)
MMLB = MegaPounds
TONS (2000 LB)
