Chapter 2. Understanding the Keypad, Menu System & Displays
DM5E Operating Manual 15
2.3 Working with the Configuration Display (cont.)
• BACKLIGHT - Turns the display backlight feature to ON, OFF, or AUTO (AUTO switches backlighting ON whenever a key is pressed or
the probe is connected).
• CONTRAST - Select this control and then press or to adjust the display contrast level.
• LANGUAGE - Sets the instrument display language (see Section 3.2 on page 21).
• BSCAN MINIMUM - Sets the minimum value that can be drawn when BSCAN is processing (see Section 3.2.1 on page 23).
• BSCAN MAXIMUM - Sets the maximum value that can be drawn when BSCAN is processing (see Section 3.2.1 on page 23).
• DUAL MULTI - Used to switch between Dual Multi and IP test modes, when Dual Multi option is allowed (see Section 3.2 on page 21).
• READING HOLD - Can be set to hold the last measurement value when the probe is uncoupled in measurement mode (see Section 3.2 on
page 21).
