GE Druck ADTS 2 Series

Druck ADTS 2XX User Manual 2
K0451 Issue No. 1
FIGURE 1-2 ADTS 2XX GENERAL VIEW
Operating Environment
Usage Indoor and outdoor
Altitude range -1500ft to 7500ft
Temperature range 0°C to 50°C
Humidity range 0 to 95% non-condensing
Rated pollution degree II
Hand terminal
connector
Touch screen
and display
Power supply
indicator
Power supply
switch
Calibration
enable switch
Power supply
connector
Static 1 (Ps1)
channel
connector
Static 2 (Ps2)
channel
connector
Pitot (Pt)
channel
connector
Do not obstruct
this vent
Earth/ground
connection stud
Water filter
drain vent
