4-32 F650 Digital Bay Controller GEK-106310AB
4.1 ENERVISTA 650 SETUP SOFTWARE INTERFACE 4 HUMAN INTERFACES. SETTINGS & ACTUAL VALUES
4
4.1.12 SECURITY MENU OVERVIEW
The security menu includes all the menus related to security control in EnerVista 650 Setup. EnerVista 650 Setup security
users and passwords are not related to passwords in HMI. Each security level has its own access for HMI management
and EnerVista 650 Setup management.
Table 4.25: GENERAL OVERVIEW OF SECURITY MENU:
Options enabled only in On-line mode are marked as (*). Options enabled only in Off-line mode are marked as (**)
4.1.13 VIEW MENU OVERVIEW
The view menu includes the computer screen to start communicating with the relay, the different update procedures
available in device: firmware, operative system, web server and other file storing capabilities (upload and download info
files to/from relay).
The ModBus memory map is detailed in the complete instruction manual (English only) and can be obtained from EnerVista
650 Setup program.
Table 4.26: GENERAL OVERVIEW OF VIEW MENU:
Options enabled only in On-line mode are marked as (*). Options enabled only in Off-line mode are marked as (**)
4.1.14 HELP MENU OVERVIEW
Complete instructions manual and data about EnerVista 650 Setup release.
Table 4.27: GENERAL OVERVIEW OF HELP MENU:
SECURITY
Login User (*) Log on menu for EnerVista 650 Setup. Enabled after security control has
been enabled in user management menu.
Change Password (*) Menu to change passwords and establish password recovering
questions.
User Management (*) User management dialog box.
VIEW
Traces (*) To inspect ModBus communication traces between the EnerVista 650
Setup and the relay.
ModBus Memory map Complete ModBus memory map description.
Languages (**) Option to change the EnerVista 650 Setup default language. Only
available if the relay is not communicating and no file (*650) is open.
HELP
Instructions Manual Instructions manual in the language selected in "View>Languages"
menu.
GE Mulitlin on the Web GE Multilin web page link.
About EnerVista 650
Setup
Release version and date of EnerVista 650 Setup program.
