6.4.8 REMOTE OUTPUTS
Actual > Inputs/Outputs > Remote Outputs > DNA
This screen provides the status of the 32 DNA remote outputs.
Table 6–53: DNA STATUS
Actual > Inputs/Outputs > Remote Outputs > UserSt
This screen provides the status of the 64 UserSt remote outputs.
Table 6–54: USER ST STATUS
Actual > Inputs/Outputs > Remote Outputs > Remote GOOSE Dig Outputs
This screen provides the status of the 32 Remote GOOSE Digital Outputs.
Table 6–55: REMOTE GOOSE DIGITAL OUTPUTS STATUS
DNA STATUS
DNA 1
DNA 2
DNA 3
...
DNA 32
USERST STATUS
UserSt 1
UserSt 2
UserSt 3
...
UserSt 64
REMOTE GOOSE DIG OUTPUTS STATUS
Rem GOOSE Dig Out 1
Rem GOOSE Dig Out 2
Rem GOOSE Dig Out 3
...
Rem GOOSE Dig Out 32
