6.4 INPUTS / OUTPUTS 6 ACTUAL VALUES
6
6.4.9 REMOTE INPUTS
Actual > Inputs/Outputs > Remote Intputs > Remote Input
This screen provides the status of the 32 remote inputs.
Table 6–56: REMOTE INPUTS STATUS
Actual > Inputs/Outputs > Remote Intputs > Remote Device
This screen provides the status of the 16 remote devices.
Table 6–57: REMOTE DEVICE STATUS
Actual > Inputs/Outputs > Remote Outputs > Remote GOOSE Digital Inputs
This screen provides the status of the 32 Remote GOOSE Digital Inputs.
Table 6–58: REMOTE GOOSE DIG INPUTS STATUS
Actual > Inputs/Outputs > Remote Outputs > Remote GOOSE Analog Inputs
This screen provides the values of the 16 Remote GOOSE Analog Inputs. Eight of them are float type and the other eight
are integer type.
Table 6–59: REMOTE GOOSE ANALOG INPUTS STATUS
REMOTE INPUTS STATUS
Remote Input 1
Remote Input 2
Remote Input 3
...
Remote Input 32
REMOTE DEVICE STATUS
Remote Device 1
Remote Device 2
Remote Device 3
...
Remote Device 16
REMOTE GOOSE DIG INPUTS STATUS
Rem GOOSE Dig Inp 1
Rem GOOSE Dig Inp 2
Rem GOOSE Dig Inp 3
...
Rem GOOSE Dig Inp 32
REMOTE GOOSE ANALOG INPUTS STATUS
Rem Ana Inp FLOAT 1
Rem Ana Inp FLOAT 2
Rem Ana Inp FLOAT 3
...
Rem Ana Inp FLOAT 8
Rem Ana Inp INT 1
Rem Ana Inp INT 2
Rem Ana Inp INT 3
...
Rem Ana Inp INT 8
