6-4 F650 Digital Bay Controller GEK-106310AB
6.2 STATUS 6 ACTUAL VALUES
6
6.2.3.2 PHASE CURRENT
This screen shows the pickup and trip for all phase instantaneous and time overcurrent elements in the F650 and block and
operation signals provided by the phase directional units. Any of these two events of any phase element will light up the
corresponding LED in this screen, and it will remain lit as the associated function remains in pickup or operation. All the
values are provided for phases and total as shown on the table below.
This screen is accessed in menu: Actual> Status > Protection > Phase Current, and includes the following signaling
LEDs:
Table 6–5: PHASE CURRENT ACTUAL VALUES
PHASE IOC ACTUAL VALUES PHASE IOC ACTUAL VALUES PHASE DIRECTIONAL ACTUAL VALUES
PH IOC1 HIGH A / B / C PKP PH TOC1 HIGH A / B / C PKP PHASE DIR1 BLOCK A
PH IOC1 HIGH A / B / C OP PH TOC1 HIGH A / B / C OP PHASE DIR1 A OP
PH IOC1 HIGH PKP PH TOC1 HIGH PKP PHASE DIR1 BLOCK B
PH IOC1 HIGH OP PH TOC1 HIGH OP PHASE DIR1 B OP
PH IOC2 HIGH A / B / C PKP PH TOC2 HIGH A / B / C PKP PHASE DIR1 BLOCK C
PH IOC2 HIGH A / B / C OP PH TOC2 HIGH A / B / C OP PHASE DIR1 C OP
PH IOC2 HIGH PKP PH TOC2 HIGH PKP PHASE DIR2 BLOCK A
PH IOC2 HIGH OP PH TOC2 HIGH OP PHASE DIR2 A OP
PH IOC3 HIGH A / B / C PKP PH TOC3 HIGH A / B / C PKP PHASE DIR2 BLOCK B
PH IOC3 HIGH A / B / C OP PH TOC3 HIGH A / B / C OP PHASE DIR2 B OP
PH IOC3 HIGH PKP PH TOC3 HIGH PKP PHASE DIR2 BLOCK C
PH IOC3 HIGH OP PH TOC3 HIGH OP PHASE DIR2 C OP
PH IOC1 LOW A / B / C PKP PH TOC1 LOW A / B / C PKP PHASE DIR3 BLOCK A
PH IOC1 LOW A / B / C OP PH TOC1 LOW A / B / C OP PHASE DIR3 A OP
PH IOC1 LOW PKP PH TOC1 LOW PKP PHASE DIR3 BLOCK B
PH IOC1 LOW OP PH TOC1 LOW OP PHASE DIR3 B OP
PH IOC2 LOW A / B / C PKP PH TOC2 LOW A / B / C PKP PHASE DIR3 BLOCK C
PH IOC2 LOW A / B / C OP PH TOC2 LOW A / B / C OP PHASE DIR3 C OP
PH IOC2 LOW PKP PH TOC2 LOW PKP
PH IOC2 LOW OP PH TOC2 LOW OP
PH IOC3 LOW A / B / C PKP PH TOC3 LOW A / B / C PKP
PH IOC3 LOW A / B / C OP PH TOC3 LOW A / B / C OP
PH IOC3 LOW PKP PH TOC3 LOW PKP
PH IOC3 LOW OP PH TOC3 LOW OP
