GEK-106310AB F650 Digital Bay Controller 7-11
7 IEC 61850 PROTOCOL 7.2 IEC 61850 PROFILE FOR F650
7
1.2 ACSI BASIC conformance statement
1.3 ACSI MODELS conformance statement
CLIENT/
SUBSCRIBER
SERVER/
PUBLISHER
VALUE/
COMMENTS
CLIENT-SERVER ROLES
B11 Server side (of TWO-PARTY APPLICATION-
ASSOCIATION)
-Y
B12 Client side of (TWO-PARTY APPLICATION-
ASSOCIATION)
-N
SCSMS SUPPORTED
B21 SCSM: IEC 6185-8-1 used - Y
B22 SCSM: IEC 6185-9-1 used - N
B23 SCSM: IEC 6185-9-1 used - N
B24 SCSM: other - N
GENERIC SUBSTATION EVENT MODEL (GSE)
B31 Publisher side - Y Both GSSE and
GOOSE
B32 Subscriber side Y - Both GSSE and
GOOSE
TRANSMISSION OF SAMPLED VALUE MODEL (SVC)
B41 Publisher side - N
B42 Subscriber side N -
CLIENT/
SUBSCRIBER
SERVER/
PUBLISHER
VALUE/
COMMENTS
If Server side (B11) supported
M1 Logical device - Y
M2 Logical node - Y
M3 Data - Y
M4 Data set - Y
M5 Substitution - N
M6 Setting group control - Y
Reporting
M7 Buffered report control - Y
M7-1 sequence-number - Y
M7-2 report-time-stamp - Y
M7-3 reason-for-inclusion - Y
M7-4 data-set-name - Y
M7-5 data-reference - Y
M7-6 buffer-overflow - Y
M7-7 entryID - Y
M7-8 BufTm - Y
M7-9 IntgPd - Y
M7-10 GI - Y
M8 Unbuffered report control - Y
M8-1 sequence-number - Y
M8-2 report-time-stamp - Y
M8-3 reason-for-inclusion - Y
M8-4 data-set-name - Y
M8-5 data-reference - Y
M8-6 BufTm - Y
