7-54 F650 Digital Bay Controller GEK-106310AB
7.2 IEC 61850 PROFILE FOR F650 7 IEC 61850 PROTOCOL
7
2 PIXIT for Server model
3 PIXIT for Dataset model
Description Value / Clarification
Which analogue value (MX) quality bits are supported
(can be set by server)
Validity:
Y Good,
N Invalid,
N Reserved,
N Questionable
N Overflow
N OutofRange
N BadReference
N Oscillatory
N Failure
N OldData
N Inconsistent
N Inaccurate
Source:
Y Process
N Substituted
N Test
N OperatorBlocked
Which status value (ST) quality bits are supported (can be
set by server)
Validity:
Y Good,
N Invalid,
N Reserved,
N Questionable
N BadReference
N Oscillatory
N Failure
N OldData
N Inconsistent
N Inaccurate
Source:
Y Process
N Substituted
N Test
N OperatorBlocked
What is the maximum number of data values in one
GetDataValues request
MMS PDU SIZE / 4
What is the maximum number of data values in one
SetDataValues request
MMS PDU SIZE / 4
Additional Items:
Behaviour of stepSize attribute checks When a client attempts to write value of setVal (CDC ING)
or setMag (CDC ASG) which is not a multiple of stepSize
attribute of assciated CF then the device will truncate the
value to the nearest stepSize not greater than the value
intended to be written.
Description Value / Clarification
What is the maximum number of data elements in one
data set
Data sets cannot be created via MMS services.
Data sets can be created via ICD/CID file and maximum
number of elements in one data set is 64. The exception to
that is the predefined data set “eveGGIO1$ST” which
contains 192 elements.
How many persistent data sets can be created by one or
more clients
Data sets cannot be created via MMS services.
Data sets can be created via ICD/CID file and maximum
number of all persistent data sets in F650 relay is 20.
How many non-persistent data sets can be created by one
or more clients
0
