13-2 F650 Digital Bay Controller GEK-106310AB
13.1 SYMPTOMS AND RECOMMENDED ACTIONS 13 F650 TROUBLESHOOTING GUIDE
13
CATEGORY SYMPTOM POSSIBLE CAUSE RECOMMENDED ACTION
Communications Cannot see properly
the web server in F650
with Windows XP.
Some windows are in
grey with a red cross
mark.
1.- Disabled Java options in Advanced
Internet Explorer properties or high
level of security
2.- Nor Java Virtual Machine installed.
1.1- Go to Advanced in Internet
options
for Internet explorer and select the
three selections in Microsoft VM (Java
Virtual Machine) and deselect any
other virtual machine not Microsoft, for
example SUN.
In case Microsoft VM is not installed in
the computer, the user must install it
using the Microsoft VM installation
program msjavx86.exe
For internet explorer 6.0 or higher it is
not included by default.
1.2.- Try to set a lower level of security
in
internet explorer options.
1.3.-Delete temporary internet files in
"General" screen in internet explorer
options.
Communication Enervista 650 Setup
does not retrieve osc,
fault reports and Data
Logger files
Bad communication in TFTP using
Windows 2000
Disable and Enable the Ethernet
connection on Control Panel inside
Windows 2000. Try again
2.1- Install either Microsoft or Sun Java
Virtual Machine
Communication Enervista 650 Setup
does not retrieve osc,
fault reports and Data
Logger files
Bad communication in TFTP using
Windows 2000
Disable and Enable the Ethernet
connection on Control Panel inside
Windows 2000. Try again to retrieve
files from relay
Firmware and bootware upgrade
Bootware The relay gets stuck
during the upgrading
process after switching
off and on the relay,
giving the following
error message:
“ERROR Setting relay
in configuration mode.
Retry?
- The relay does not communicate via
the front RS232 port
To perform the bootware upgrading
process it is necessary to connect the
unit thought the front RS232 port.
check:
• Serial cable correct(straightthrouhg)
and undamaged.
• Settings selection in Enervista 650
Setup Communication>Computer
Settings”:
o Com port selected must be the
one that is being used to perform
this procedure
o Parity set to NONE
o Baudrate set to 19200
o Control type: No control type
o Modbus slave number: any
Note: if the bootware upgrading
procedure got stuck at this point
the relay will not be upgraded. After
switching it off and on will continue
working with the former firmware
and bootware versions.

GE F650 Specifications

General

Model	F650
Category	Controller
Frequency	50/60 Hz
Display	LCD
Type	Feeder Protection Relay
Application	Feeder Protection and Control
Communication Protocols	DNP3, Modbus, IEC 61850
Protection Functions	Overcurrent, Earth Fault
Manufacturer	General Electric
Input Voltage	24-250 VDC/VAC
