A-34 F650 Digital Bay Controller GEK-106310AB
A.1 LOGIC OPERANDS APPENDIX A
A
OPERANDS - F650 - MODEL FX - GX
INTERNAL SYSTEM STATUS (CONT.)
wattmetric Ground Fault Low (Logic Operands)
32N1 LOW BLOCK wattmetric Ground Fault Element Block Low Level
Group 1
32N1 LOW PKP wattmetric Ground Fault Element Global Pickup (current,
voltage and power) Low Level Group 1
32N1 LOW OC PKP wattmetric Ground Fault Element Overcurrent Pickup
Low Level Group 1
32N1 LOW OP wattmetric Ground Fault Element Operation Low Level
Group 1
32N2 LOW BLOCK wattmetric Ground Fault Element Block Low Level
Group 2
32N2 LOW PKP wattmetric Ground Fault Element Global Pickup (current,
voltage and power) Low Level Group 2
32N2 LOW OC PKP wattmetric Ground Fault Element Overcurrent Pickup
Low Level Group 2
32N2 LOW OP wattmetric Ground Fault Element Operation Low Level
Group 2
32N3 LOW BLOCK wattmetric Ground Fault Element Block Low Level
Group 3
32N3 LOW PKP wattmetric Ground Fault Element Global Pickup (current,
voltage and power) Low Level Group 3
32N3 LOW OC PKP wattmetric Ground Fault Element Overcurrent Pickup
Low Level Group 3
32N3 LOW OP wattmetric Ground Fault Element Operation Low Level
Group 3
wattmetric Ground Fault Low (Power
Measurements)
32N1 LOW POWER wattmetric Ground Fault Element Low Level Group 1
Power Value (watts)
32N2 LOW POWER wattmetric Ground Fault Element Low Level Group 2
Power Value (watts)
32N3 LOW POWER wattmetric Ground Fault Element Low Level Group 3
Power Value (watts)
