GEK-106310AB F650 Digital Bay Controller B-65
APPENDIX B B.7 MEMORY MAP
B
Ajuste Rango de Entrada Analogica H (8 elementos) - Board H Analog Input Range Settings (8 items)
0x3005 Range_H_01 F012 1 R/W 1 0=NONE
1=-1 to 0 mA
2= 0 to 1mA
3=-1 to 1mA
4= 0 to 5 mA
5= 0 to 10mA
6= 0 to 20mA
7= 4 to 20mA
... ... ... ... ... ... ... ...
0x300C Range_H_08 F012 1 R/W 1 0=NONE
1=-1 to 0 mA
2= 0 to 1mA
3=-1 to 1mA
4= 0 to 5 mA
5= 0 to 10mA
6= 0 to 20mA
7= 4 to 20mA
Ajuste Rango de Medida de Entrada Analógica H (8 elementos) - Board H: Analog Input Measurement Range (8 items)
0x300D Min Value_H_01 F003 1 R/W 2 [-9999.99 , 9999.99]
0x300F Min Value_H_02 F003 1 R/W 2 [-9999.99 , 9999.99]
... ... ... ... ... ... ... ...
0x301B Min Value_H_08 F003 1 R/W 2 [-9999.99 , 9999.99]
0x301D Max Value_H_01 F003 1 R/W 2 [-9999.99 , 9999.99]
0x301F Max Value_H_02 F003 1 R/W 2 [-9999.99 , 9999.99]
... ... ... ... ... ... ... ...
0x302B Max Value_H_08 F003 1 R/W 2 [-9999.99 , 9999.99]
0x30FF Confirmation address W 1
Ajustes Tarjeta J (MODULO CIO) - Board J Settings (CIO MODULE)
Ajustes Tipo Tarjeta J - Board J Board Type Settings
0x3100 I/O Board Type_J F012 1 R/W 1 0=NONE
1=16INP + 8OUT
2=8INP + 8OUT + SUPV
4=32INP
5=16INP + 8ANA
Ajustes de Tensión Tarjeta J - Board J Voltage Settings
0x3101 Voltage Threshold A_J F004 1 R/W 1 [10 , 230] V
0x3102 Voltage Threshold B_J F004 1 R/W 1 [10 , 230] V
0x31A6 Voltage Threshold C_J F004 1 R/W 1 [10 , 230] V
0x31A7 Voltage Threshold D_J F004 1 R/W 1 [10 , 230] V
Ajustes Tiempo Antirrebotes Tarjeta J - Board J Debounce Time Settings
0x3103 Debounce Time A_J F004 1 R/W 1 [1 , 50] ms
0x3104 Debounce Time B_J F004 1 R/W 1 [1 , 50] ms
0x31A8 Debounce Time C_J F004 1 R/W 1 [1 , 50] ms
0x31A9 Debounce Time D_J F004 1 R/W 1 [1 , 50] ms
ADDRESS BIT NAME FORMAT STEP MODE LENGTH MISCELLANEOUS
