C-18 F650 Digital Bay Controller GEK-106310AB
C.6 BINARY OUTPUT AND CONTROL RELAY OUTPUT APPENDIX C
C
C.6BINARY OUTPUT AND CONTROL RELAY OUTPUT
Supported Control Relay Output Block fields: Pulse On.
The F650 relay provides 24 DNP Binary/Control Output points. These outputs are mapped to the first 24 commands
configured in the F650. Executing a command is equal to activate the PLC equation that was attached to this command.
Thus all of the 24 DNP Binary/Control Output points are pulsed points. It means that only Pulse On flag will be accepted in
DNP control operations on those points. All commands have configurable names. Changing the command’s name can be
done using the EnerVista 650 Setup program.
BINARY OUTPUT STATUS POINTS
Object Number: 10
Request Function Codes supported: 1 (read)
Default Variation Reported when variation 0 requested: 2 (Binary Output Status)
CONTROL RELAY OUTPUT BLOCKS
Object Number: 12
Request Function Codes supported: 3 (select), 4 (operate), 5 (direct operate), 6 (direct operate, no ack)
BINARY/CONTROL OUTPUT POINTS BINARY/CONTROL OUTPUT POINTS
POINT
INDEX
NAME/DESCRIPTION POINT
INDEX
NAME/DESCRIPTION
0 OPERATION1 12 OPERATION13
1 OPERATION2 13 OPERATION14
2 OPERATION3 14 OPERATION15
3 OPERATION4 15 OPERATION16
4 OPERATION5 16 OPERATION17
5 OPERATION6 17 OPERATION18
6 OPERATION7 18 OPERATION19
7 OPERATION8 19 OPERATION20
8 OPERATION9 20 OPERATION21
9 OPERATION10 21 OPERATION22
10 OPERATION11 22 OPERATION23
11 OPERATION12 23 OPERATION24
