GE F650 User Manual

3-12 F650 Digital Bay Controller GEK-106310AB
3.5 TRANSCEIVER OPTICAL POWER BUDGET VERSUS LINK LENGTH 3 HARDWARE
3
3.5TRANSCEIVER OPTICAL POWER BUDGET VERSUS LINK LENGTH
Optical Power Budget (OPB) is the available optical power for a fiber optic link to accommodate fiber cable losses plus
losses due to in-line connectors, splices, optical switches, and to provide margin for link aging and unplanned losses due to
cable plant reconfiguration and repair.
OPB (DB) FIBER OPTIC CABLE
LENGTH (KM)
62.5/125 μm 50/125 μm
11.4 8 0
10.9 7.4 0.3
10.5 7.1 0.5
9.6 6.2 1.0
8.5 5.3 1.5
7.3 4.3 2.0
63.32.5

GE F650 Specifications

General

Model	F650
Category	Controller
Frequency	50/60 Hz
Display	LCD
Type	Feeder Protection Relay
Application	Feeder Protection and Control
Communication Protocols	DNP3, Modbus, IEC 61850
Protection Functions	Overcurrent, Earth Fault
Manufacturer	General Electric
Input Voltage	24-250 VDC/VAC
