GE F650 User Manual

F-2 F650 Digital Bay Controller GEK-106310AB
F.1 IEC 60870-5-103 PROTOCOL APPENDIX F
F
Status indications in monitor direction
Supervision indications in monitor direction
Earth fault indications in monitor direction
INF Semantics F650 Identifier F650 Data Text
X <16> Auto-recloser active 4591 AR READY
X <17> Teleprotection active 3895 LOCAL
<18> Protection active
X <19> LED reset 6839 RESET LEDS
<20> Monitor direction blocked
<21> Test mode
<22> Local parameter setting
X <23> Characteristic 1 4875 GROUP 1 ACT ON
X <24> Characteristic 2 4876 GROUP 2 ACT ON
X <25> Characteristic 3 4877 GROUP 3 ACT ON
<26> Characteristic 4
<27> Auxiliary input 1
<28> Auxiliary input 2
<29> Auxiliary input 3
<30> Auxiliary input 4
INF Semantics F650 Identifier F650 Data Text
<32> Measurand supervision I
<33> Measurand supervision V
<35> Phase sequence supervision
X
<36> Trip circuit supervision 4539 BREAKER FAIL
SUPERVISION
<37> I>> back-up operation
X <38> VT fuse failure 4545 VT FUSE FAILURE
<39> Teleprotection disturbed
<46> Group warning
<47> Group alarm
INF Semantics F650 Identifier F650 Data Text
<48> Earth fault L1
<49> Earth fault L2
<50> Earth fault L3
<51> Earth fault forward, i.e. line
<52> Earth fault reverse, i.e. busbar

GE F650 Specifications

General

Model	F650
Category	Controller
Frequency	50/60 Hz
Display	LCD
Type	Feeder Protection Relay
Application	Feeder Protection and Control
Communication Protocols	DNP3, Modbus, IEC 61850
Protection Functions	Overcurrent, Earth Fault
Manufacturer	General Electric
Input Voltage	24-250 VDC/VAC
